油煙凈化器廣泛適用于賓館、飯店，餐廳、食堂、食品廠以及燃油鍋爐等排放油煙的場所；油煙凈化器安裝在排煙風機的作用下、油煙氣混合污染物進入初級凈化整流腔、腔內的特殊結構對污染物進行均衡整流的同時，利用親油性的濾料對大顆粒油霧滴進行吸附截留，分離出來的油水液體被集中回收。脫除油水的煙氣均衡地進入次收。脫除油水的煙氣均衡地進入次級柵狀高壓場。油煙氣在高壓場的作用下，被電離、分解，吸咐 、碳化，同時場中產生的活性因子臭氧（O3），對煙氣中的有毒成份和異味進行分解和除味。
The price of lampblack purifier is widely used in hotels, restaurants, canteens, food factories, oil fired boilers and other places that emit lampblack; The lampblack purifier is installed under the action of the smoke exhaust fan. When the mixed pollutants of lampblack and gas enter the primary purification rectifier cavity and the special structure of the cavity carries out balanced rectification of the pollutants, the lipophilic filter material is used to adsorb and intercept the large particles of oil droplets, and the separated oil-water liquid is centrally recycled. The flue gas from oil-water removal enters the secondary collector in a balanced way. The flue gas from oil-water removal enters the secondary grid high pressure field in a balanced manner. Under the action of high-pressure field, lampblack gas is ionized, decomposed, absorbed and carbonized. At the same time, the active factor ozone (O3) generated in the field decomposes and deodorizes the toxic components and odor in the smoke.
油煙凈化器安裝/特點
Installation/features of lampblack purifier
①電場分布裝置采用活動結構，拆裝自由，清洗方便；
① The electric field distribution device adopts a movable structure, which can be disassembled freely and cleaned conveniently;
②組合式箱體，可根據需要自由選擇進出風口方位，安裝方便；
② The combined box can freely select the direction of the air inlet and outlet according to the needs, which is convenient for installation;
③設有過流、過壓、觸電、漏電、故障保護裝置；
③ It is equipped with over-current, over-voltage, electric shock, leakage and fault protection devices;
④可實現設備與控制分離操作；⑤結構緊湊、新穎、體積小、重量輕；
④ Separation of equipment and control can be realized; ⑤ Compact and novel structure, small volume and light weight;
⑥電場 電壓穩定，不會隨電場電流的增加而下降；
⑥ The electric field voltage is stable and will not decrease with the increase of electric field current;
⑦油煙凈化器阻力小、噪音低、能耗低、可靠性高、過濾率高；
⑦ The lampblack purifier has low price resistance, low noise, low energy consumption, high reliability and high filtration rate;
酒店油煙凈化器必須跟風機搭配使用才能達到事半功倍的效果。凈化的目的是為了排放，選擇風機的目的就是要確保風量的排放。所以工程中風機的選擇是個，下面小編就著重介紹一下風機的選用。常用的排煙風機有軸流風機、風柜機和離心風機。
The hotel lampblack purifier must be used together with the fan to achieve twice the result with half the effort. The purpose of purification is to discharge, and the purpose of fan selection is to ensure the discharge of air volume. Therefore, the selection of fans in the project is a key point. The following sections will focus on the selection of fans. Common smoke exhaust fans include axial flow fan, fan cabinet fan and centrifugal fan.
1.軸流風機以前應用較多，在設計安裝低空排放油煙凈化器時常常用到。
1. Axial flow fans have been widely used in the past, and they are often used in the design and installation of low altitude oil smoke purifiers.
2.風柜機全壓中等，風量可以調節，且噪聲較低，常在集煙罩距油煙排放口距離中等的廚房排煙系統中選用。
2. The full pressure of the fan cabinet is medium, the air volume is adjustable, and the noise is low. It is often used in the kitchen smoke exhaust system where the distance between the smoke collecting hood and the lampblack outlet is medium.
3.離心風機全壓和風量都可以調節，但由于噪聲較大，常需要做降噪處理。
3. The total pressure and air volume of the centrifugal fan can be adjusted, but due to the large noise, noise reduction is often required.
Jinan lampblack purifier focuses on the production and processing of Jinan lampblack purifier, kitchen smoke exhaust hood and other products. For more highlights, please click here: http://www.yulegw45.cn , we will have more wonderful content for you to check
